| Accuracy (Temperature) |
±0.3°C, ±0.5°F |
| Accuracy (ISE) |
±0.2 mV or ±0.05% of the reading, whichever is greater |
| Accuracy (mV) |
±0.2 mV or ±0.05% of the reading, whichever is greater |
| Accuracy (pH) |
±0.002 pH |
| Calibration |
pH, ORP, Ion Concentration, Temperature |
| Calibration Points |
1 to 5 (pH), 1 (ORP), 1 to 5 (ion), 1 to 2 (temperature) |
| Calibration Points (pH) |
1 to 5 points |
| Calibration Points (ISE) |
Up to 5 |
| Temperature Range |
-30°C to +130°C (-22°F to +266°F) |
| Temperature Selection |
Automatic with ATC temperature sensor, ambient or manual |
| Temperature Probe Calibration |
1 or 2 point temperature offset calibration |
| Range (pH) |
-2 to 20 pH |
| Range (mV) |
-2000 to 2000 mV |
| Range (ISE) |
0.0001 to 19999 |
| Range (ORP) |
-2000 to 2000 mV |
| Range (Relative mV) |
-2000 to 2000 mV |
| Resolution (pH) |
0.1, 0.01 or 0.001 pH |
| Resolution (mV) |
0.1 mV |
| Resolution (Temperature) |
0.1°C, 0.1°F |
| Resolution (ISE) |
0.0001 minimum, 1 to 5 digits |
| Inputs |
Channel 1: BNC for pH, ORP or ISE, 8-pin MiniDIN for ATC, pin-tip for reference;
Channel 2: BNC for pH, ORP or ISE, 8-pin MiniDIN for ATC, pin-tip for reference |
| Outputs |
USB flash drive, computer or printer |
| Measurement Modes |
pH, ORP with mV and Temperature, Ion Concentration (ISE) with Temperature |
| Display Type |
7-inch High-resolution Color Graphic LCD with Backlight option |
| Memory |
Non-volatile |
| Data Points |
10,000 with Date and Time Stamp |
| Log Function Type |
Automatic with Auto-Read and Timed Read Modes, Manual with Continuous Read Mode |
| Alarm Output |
Calibration reminder alarm, high and low limit alarm per parameter |
| Keypad |
Capacitive touchscreen user interface |
| Languages |
Chinese, English, French, German, Italian, Japanese, Korean, Portuguese, Spanish |
| Isopotential Point |
7.000 pH; 1.000 ion concentration |
| Channels |
2 |
| Dimensions (L x W x H) |
218.9 x 153.2 x 91.33mm (8.62 x 6.03 x 3.60 inch) |
| Weight |
1kg (2.20 lbs) |
| Certifications/Compliance |
CE, TUV 3-1, FCC Class A |
| Warranty |
2 year meter warranty |
