| Accuracy (Polarographic DO) |
±2% saturation; ±0.02 mg/L or ppm |
| Accuracy (Temperature) |
±0.3°C, ±0.5°F |
| Accuracy (RDO) |
±2% saturation; ±0.02 mg/L or ppm |
| Accuracy (Barometer) |
±6.0 mmHg; ±0.008 bar |
| Accuracy (DO) |
±2% saturation; ±0.02 mg/L or ppm |
| Calibration Modes |
Water-saturated air (100% and 0% saturation), air-saturated water (100% and 0% saturation) or custom concentration value (Winkler) |
| Range (DO) |
0.0 to 600.0% saturation; 0.01 to 90.0 mg/L or ppm |
| Range (RDO) |
0.0 to 600.0% saturation; 0.01 to 90.0 mg/L or ppm |
| Range (Polarographic DO) |
0.0 to 600.0% saturation; 0.01 to 90.0 mg/L or ppm |
| Pressure Range |
400.0 to 850.0 mmHg; 0.533 to 1.133 bar |
| Relative Humidity Range |
5 to 85%, non-condensing |
| Saturation Range Polarographic DO |
0.0 to 600.0% saturation |
| Resolution (Polarographic DO) |
0.1, 1% saturation; 0.01, 0.1 mg/L or ppm |
| Resolution (DO) |
0.1, 1% saturation; 0.01, 0.1 mg/L or ppm |
| Resolution (RDO) |
0.1, 1% saturation; 0.01, 0.1 mg/L or ppm |
| Resolution (Temperature) |
0.1°C, 0.1°F |
| Saturation Relative Accuracy (RDO) |
±2% saturation |
| Saturation Resolution (Polarographic DO) |
0.1, 1% saturation |
| Saturation Range (RDO) |
0.0 to 600.0% saturation |
| Saturation Relative Accuracy (Polarographic DO) |
±2% saturation |
| Saturation Resolution (RDO) |
0.1, 1% saturation |
| Temperature Range |
-30.0°C to +130.0°C |
| Temperature Selection |
Automatic with ATC temperature sensor, ambient or manual |
| Temperature Probe Calibration |
1 or 2 point temperature offset calibration |
| Inputs |
9-pin MiniDIN for dissolved oxygen with ATC |
| Outputs |
USB flash drive, computer or printer |
| For Use With (Application) |
Wide variety of dissolved oxygen samples using optical DO electrode |
| Barometric Pressure Correction |
Yes, automatic with built-in barometer or manual |
| Measurement Modes |
Dissolved Oxygen (mg/L with Temperature and Barometric Pressure), Dissolved Oxygen (ppm with Temperature and Barometric Pressure), Dissolved Oxygen (% Saturation with Temperature and Barometric Pressure) |
| Sensor Types |
RDO Optical Dissolved Oxygen Sensor |
| Memory |
Non-volatile |
| Data Points |
10,000 with Date and Time Stamp |
| Log Function Type |
Automatic with Auto-Read and Timed Read Modes, Manual with Continuous Read Mode |
| Alarm Output |
Calibration reminder alarm, high and low limit alarm per parameter |
| IP Rating |
IP54 |
| AC Adapter |
Universal 100-240 V 50/60 Hz power supply with wall plugs for US/Japan, Euro, UK/Singapore, Australia/New Zealand and China outlets
|
| Keypad |
Capacitive touchscreen user interface |
| Languages |
Chinese, English, French, German, Italian, Japanese, Korean, Portuguese, Spanish |
| Methods |
10 |
| Probe Type |
Polarographic or optical DO electrode |
| Salinity Factor |
0.0 to 50.0 ppt |
| Dimensions (L x W x H) |
218.9 x 153.2 x 91.33mm (8.62 x 6.03 x 3.60 inch) |
| Weight |
1.00kg (2.20 lbs.) |
| Certifications/Compliance |
CE, TUV 3-1, FCC Class A |
| Warranty |
2 year meter warranty |
