| Accuracy (Conductivity) |
±0.5% reading |
| Accuracy (Salinity) |
±0.5% reading |
| Accuracy (TDS) |
±0.5% reading |
| Accuracy (Temperature) |
±0.3°C, ±0.5 °F |
| Calibration |
Conductivity, TDS, Salinity, Temperature |
| Calibration Points (Conductivity) |
1 to 5 points |
| Calibration Points |
1 to 5 (conductivity), 1 to 5 (TDS), 1 (salinity), 1 to 2 (temperature) |
| Temperature Compensation |
Linear (0.00 to 10.00%/°C), nLFn (non-linear natural water), nLFu (non-linear ultra-pure water), EP/USP or off |
| Temperature (Metric) Reference |
5, 10, 15, 20, 25 or 30°C |
| Temperature Range |
-30°C to +130°C (-22°F to +266°F) |
| Temperature Selection |
Automatic with ATC temperature sensor, ambient or manual |
| Temperature Probe Calibration |
1 or 2 point temperature offset calibration |
| Range (Conductivity) |
0.010µS/cm to 3000mS/cm |
| Range (Salinity) |
0.010 to 80.00 ppt; 0.01 to 42.00 PSU; or 0.01 to 400.0% NaCl |
| Range (TDS) |
0.010 ppm to 500.0 ppt (TDS factor of 1.00); or 0.010 mg/L to 500.0g/L (TDS factor of 1.00) |
| Range (Resistivity) |
1.0 O to 100.0 MO |
| Resolution (Conductivity) |
0.001 µS/cm minimum, auto-ranging, up to 4 digits |
| Resolution (Salinity) |
0.001 ppt minimum; 0.01 PSU minimum; or 0.01% NaCl minimum, auto-ranging |
| Resolution (TDS) |
0.001 ppm or mg/L minimum, auto-ranging, up to 4 digits |
| Resolution (Temperature) |
0.1°C, 0.1°F |
| Inputs |
8-pin MiniDIN for conductivity with ATC |
| Outputs |
USB flash drive, computer or printer |
| Measurement Modes |
Conductivity with Temperature, TDS with Temperature, Salinity with Temperature, Resistivity with Temperature |
| Salinity Measurement Modes |
Natural Seawater (ppt), Practical Salinity Units (PSU), or % NaCl |
| Cell Constant |
0.100 cm-1, 0.475 cm-1, 0.550 cm-1, 1.000 cm-1, 10.00 cm-1 or user-defined from 0.001 to 199.9 cm-1 |
| TDS Factor Range |
Linear (0.01 to 10.00), ISO/EN 27888, 442, NaCl |
| Data Points |
10,000 with Date and Time Stamp |
| Log Function Type |
Automatic with Auto-Read and Timed Read Modes, Manual with Continuous Read Mode |
| Alarm Output |
Calibration reminder alarm, high and low limit alarm per parameter |
| Dimensions (L x W x H) |
218.9 x 153.2 x 91.33mm (8.62 x 6.03 x 3.60 inch) |
| Weight |
1kg (2.20 lbs) |
| Certifications/Compliance |
CE, TUV 3-1, FCC Class A |
| Warranty |
2 year meter warranty |
