Little SHOT^TM, Boekel

home > hybridization > little shot^tm, boekel

You have not viewed any products recently.

View Larger

Applications

Southern and Northern blotting processes

Pre-hybridization and stringency washes

Features

Capacity for four 35 mm diameter x 300 mm or eight 35 mm diameter x 150 mm glass bottles

PID temperature controller for rapid heat up and excellent temperature stabilty

Maximum temperature of 100°C with forced air convection

Lift off lid has "trap door" minimizing heat loss while inserting or removing bottles

Rotation speed of 0 to 20 RPM

Offset carousels ensure coverage of membranes

Small footprint - only 22cm wide

Optional carousels available

Supplied with stainless steel drip pan

Cat No	J131-15, J131-16
Model No	230500, 230500-2
Exterior (w x d x h)	21.6 cm (8½ in) x 52.1 cm (20½ in) x 30.5 cm (12 in)
Interior (w x d x h)	17.1 cm (6¾ in) x 32.4 cm (12¾ in) x 22.2 cm (8¾ in)
Net Weight:	9.5 kg (21 lbs)
Shipping Weight	11.8 kg (26 lbs.)
Electrical:	115 VAC (60 Hz) or 230 VAC (50Hz); 230W
Capacity:	4 bottles 35 mm x 300 mm 8 bottles 35 mm x 150 mm
Temperature Range:	Minimum is Ambient ±10°C. Maximum is 75°C.
Stability:	± 0.1°C
Accuracy:	± 0.5°C
Speed:	0-20 RPM fixed speed
Heat-up Rate:	Ambient to 65°C in 23 minutes
Temp. Controller Type	Programmable PID with LED display

Cat No	Vendor Part No	Description	Power	Qty	Price	Qty	UOM
J131-15	230502	Little SHOT Hybridization Oven	115VAC 60Hz	In Stock	1	Inquire		EA
J131-16	230502-2	Little SHOT Hybridization Oven	230VAC 50/60Hz	In Stock	1	Inquire		EA

Cat No	Vendor Part No	Description	Qty/UOM	Price	Qty
J131-18	230552	Spindle, Little SHOT 12 x 1.5 mL tubes	In Stock	1	$369.61	EA
J131-9	502-0300	Glass Hybridization Bottles 35 mm x 300 mm	In Stock	2	$173.80	PK
J131-10	502-0225	Glass Hybridization Bottles 35 mm x 225 mm	In Stock	2	$158.11	PK
J131-11	502-0150	Glass Hybridization Bottles 35 mm x 150 mm	In Stock	2	$142.07	PK
J131-12	502-0100	Glass Hybridization Bottles 35 mm x 100 mm	In Stock	2	$132.04	PK
J131-13	230423	Nylon Mesh Spacers 23 mm x 23 mm	In Stock	5	$67.57	PK
J131-14	230415	Nylon Mesh Spacers 15 mm x 10mm	In Stock	5	$64.75	PK
