HotPlates and Stirrers, Digital, Ceramic Top Plate
GHS-380 Group Hotplates & Stirrers
The GHS-380 group of Hotplates, Magnetic Stirrers and Magnetic Stirrer Hotplates are reliable and easy to use. The low profile and small footprint save valuable workspace. Clean up is easy with a robust chemical resistant ceramic-coated 5.5-inch square surface to ensure years of service.
Selecting the heat and stirring speed is extremely intuitive with a digital LCD display and control knobs, inputting to a microprocessor-controlled circuit for accurate, stable control of heating and stirring.
The Magnetic Stirrer and Hotplate Magnetic Stirrer Models are designed to provide a strong magnetic coupling for powerful mixing that is enabled by the maintenance free brushless DC motor. The stirrers can mix up to 5 liters of water, which allows for excellent homogeneity of solutions.
The Hotplate and Hotplate Magnetic Stirrer models are designed with a powerful 500-watt heater that provides temperatures up to 380°C. For ultimate accurate temperature control within 0.5°C, an optional PT1000 sensor and retort stand are available to measure directly in the vessel. Overtemperature protection is added should temperatures reach 420°C.
- Simple, intuitive operation
- Maintenance-free brushless DC motor
- Small footprint saves valuable bench space
- Powerful 500W heater
- Easy-to-clean ceramic coated aluminum surface
- Easy-to-read high resolution LCD display for simple, clear control
- Powerful magnetic coupling for stirring up to 5L of water
- Optional external temperature sensor control
- 5.5 x 5.5 inch ceramic coated top plate
| Type |
Hotplate Stirrer |
Hotplate |
Stirrer |
| |
H173-3 |
H173-1 |
H173-2 |
| Working area (W x D) |
140 x 140mm (5.5 x 5.5inch) |
| Working area material |
Ceramic-coated aluminum |
| Heating power |
500W |
N/A |
| Temperature range |
Ambient +5°C to 380°C |
N/A |
| Maximum stir volume |
5L |
N/A |
5L |
| Stirring speed range |
200-1500rpm |
N/A |
200-1500rpm |
| Stir bar length |
50mm (2inch) |
N/A |
50mm (2inch) |
| Voltage |
100-120v 60Hz; 200-240v 50Hz |
| Power |
510W |
| Dimensions [WxDxH] |
320×180×108mm (12.6 x 7.1 x 4.3inch) |
| Weight |
2.2kg (4.9lbs) |
| Operating temperature |
5-40°C |
| Permissible relative humidity |
80%RH (non-condensing) |
