| Catalog No |
B143-5 |
B143-6 |
B143-7 |
B143-8 |
| Model No |
PV-60 |
PV-100 |
PV-200 |
PV-500 |
| Capacity/gram |
60 x 0.01 |
100 x 0.1 |
200 x 0.1 |
500 x 0.1 |
| Decimal Ounces |
2.1 x 0.001 |
3.5 x 0.005 |
7 x 0.005 |
17.5 x 0.005 |
| Calibration Weight(standard) |
50 ±0.005g |
50 ±0.05g |
100 ± 0.05g |
200 ± 0.05g |
| Repeatability |
± Two display readability |
± Two display readability |
± Two display readability |
± Two display readability |
| Linearity |
± Two display readability |
± Two display readability |
± Two display readability |
± Two display readability |
| Sensitivity Drift |
±50ppm/°C (10-35°C / 50-95°F) |
±50ppm/°C (10-35°C / 50-95°F) |
±50ppm/°C (10-35°C / 50-95°F) |
±50ppm/°C (10-35°C / 50-95°F) |
| Stability Time |
3 seconds |
3 seconds |
3 seconds |
3 seconds |
| Operating Temp |
5-35°C / 41-95°F |
5-35°C / 41-95°F |
5-35°C / 41-95°F |
5-35°C / 41-95°F |
| Display Type |
5 digits LCD |
5 digits LCD |
5 digits LCD |
5 digits LCD |
| Power |
2 AAA size alkaline batteries (standard) |
2 AAA size alkaline batteries (standard) |
2 AAA size alkaline batteries (standard) |
2 AAA size alkaline batteries (standard) |
| Battery Life |
40 hours with alkaline batteries |
40 hours with alkaline batteries |
40 hours with alkaline batteries |
40 hours with alkaline batteries |
| Pan Size |
3.25 x 3" (WxD) |
3.25 x 3" (WxD) |
3.25 x 3" (WxD) |
3.25 x 3" (WxD) |
| Dimensions (WxDxH) |
3 x 5.3 x 0.8" |
3 x 5.3 x 0.8" |
3 x 5.3 x 0.8" |
3 x 5.3 x 0.8" |
| Supplied Accessories |
Calibration weight, 2 AAA batteries, Vinyl Carrying Case |
Calibration weight, 2 AAA batteries, Vinyl Carrying Case |
Calibration weight, 2 AAA batteries, Vinyl Carrying Case |
Calibration weight, 2 AAA batteries, Vinyl Carrying Case |
